3 Row All Aluminum Radiator B8100
3 Row All Aluminum Radiator B8100
All-Aluminum Design with Durable, TIG-Welded Construction
Core Dimensions: 26.25' H x 16.75' W x 2.00' (Core Thickness)
Light Weight Direct Bolt-On OEM Fitment or Replacement
Build-in Trans Oil Cooler (Thread Details: M12*1.25)
Top Attention: 3 Warehouses in USA & Fast Shipping, 3-6 Days Will Be Delivered
The Radiator is designed and specifically engineered to maximize cooling efficiency by up to 35%, boost engine functions and protect your car from overheating. The radiator features a lightweight core, and holds up to more coolant. The CoolingCare radiator showed a 20degF drop in outlet temp compared to the OEM. Every CoolingCare Performance Radiator is a direct OEM fit, making installation effortless, no cutting or modification is required.
This Radiator Size:
Radiator Flow: Cross Flow
Core Dimensions: 26.25' x 16.75' x 2.00'
Overall Dimensions: 30.75' x 18.75' x 2.50'
Inlet / Outlet Diameter: 1.25' /1.5'
Upper / Lower Hose Fitting: Driver / Pass
Trans Oil Cooler: Include
Mounting Type: Saddle
Mounting Specs: Vert - 22 3/8 Horizontal - 17 1/2
